ARCS-J/BT - 125 kHz + 13.56 MHz + Bluetooth® dual-frequency keypad reader

ARCS-J/BT - 125 kHz + 13.56 MHz + Bluetooth® dual-frequency keypad reader

STid has designed the Architect® Blue Hybrid 125 kHz + 13.56 MHz + Bluetooth® vandal-proof keypad reader for access control - perfect blend of three identification technologies - to facilitate your migrations to advanced security levels.

The most awarded access control reader around the worldbandeau logo Trophees STid 2017 V2

Logo of Architect blue for the ARCS-J/BT by STid Industry

The perfect blend of high security and scalability

  • Picture from the left profile of a black ARCS-J/BT by STid Industry
  • Picture from the front side of a black ARCS-J/BT by STid Industry
  • Picture from the right profile of a black ARCS-J/BT by STid Industry

Ensure secure migration

Picture for the secure migration of the ARCS-J/BT by STid Industry









The Architect® Blue Hybrid reader makes it easy to manage extensions, upgrades and technology migrations. If you need to set up a complex multi-site configuration, this reader can be used to read a range of different cards.

  • NXP MIFARE® credentials (Classic & Classic EV1, Ultralight® & Ultralight® C, Plus® & Plus® EV1, DESFire® 256, EV1 & EV2),
  • iCLASS™* and PicoPass® cards serial numbers,
  • French Ministry cards (AGENT, CIMS…) and civil aviation (STITCH),
  • CPS3 (IAS protocole) health cards,
  • smartphones compatible with Bluetooth® and NFC (HCE) technologies,
  • 125 kHz credentials (EM, Crosspoint, formats Wiegand 26, 34, 35 and 37 bits…).

Manage with ease a multi-factor identification

Both reader and keypad, the device allows a dual-identification by combining card and/or PIN code identifications.

Thanks to its various operating modes (card AND key or card OR key), you can use the keypad to identify people or to activate additional functions (activation of the intrusion alarm…).

Picture for the multi-factor security of the ARCS-J/BT

5 identification modes for a unique experience

Virtual cards promote acceptance of and compliance with the Security Policy of businesses, industries and governments.
STid Mobile ID® is so user-friendly that it makes identification instinctive.

Choose your favorite identification mode and make your access options both secure and much more intuitive!

Icon for the card identification mode of the ARCS-I/BT by STid Industry

Card mode
by placing your smartphone in front of the reader.

Icon for the slide identification mode of the ARCS-I/BT by STid Industry

Slide mode
by placing your hand close to the reader without taking out your phone.



Icon for the tap tap identification mode of the ARCS-I/BT by STid Industry

Tap Tap mode
by tapping your smartphone twice in your pocket for near or remote opening.

Icon for the remote identification mode of the ARCS-I/BT by STid Industry

Remote mode
by using your smartphone as a remote control.



Icon for the hand free identification mode of the ARCS-I/BT by STid Industry

Hands-free mode
by simply passing in front of the reader.

  See identification modes Play

Welcome to high security

Logos representing the high security of the ARCS-I/BT by STid Industry

All public encryption algorithms can be used (3DES, AES, RSA, SHA, etc.), which are recommended by official data security agencies (such as the French national agency ANSSI). The reader uses the latest MIFARE® DESFire® EV2 contactless chip technologies with new data security mechanisms:

  • Secure Messaging EV2: secure transaction method based on AES-128 with protection against interleaving and replay attacks.
  • Proximity Check : improved protection against relay attacks.


logo of eal5 for the ARCS-I/BTIt uses an EAL5+ crypto processor to improve data protection and privacy.

Logo of SECARD for the ARCS-I/BT by STid Industry

THE SOFTWARE TOOL FOR FULL CONTROL
OF YOUR SECURITY

The SECard software lets users, installers and integrators easily:

Picture of the SECARD tools compatible with the ARCS-I/BT by STid Industry

  • securely program user RFID and virtual cards,
  • create master physical or virtual badges for programming readers,
  • manage keys and security configurations.



See the flyer

Benefits

  • 100% local sandboxed programming
  • Autonomous management for securely programming RFID and Bluetooth® user cards
  • Configuration and reconfiguration of readers
  • Protection and confidentiality of user cards and the master card
  • Plug & Play tool
  • Fully compatible with AGENT, CIMS and STITCH cards
  • Complies with General Data Protection Regulation no. 2016/679 and Standard EN16571

logo sia osdp

Readers are compatible with the SIA Open Supervised Device Protocol - OSDP™ V1 & V2.

logo sscp

Readers are compatible with the latest generation of open protocol SSCP (STid Secure Common Protocol). This protocol recommended by ANSSI uses data encryption (AES) and two-way “reader-controller” authentication to ensure security before any communication is allowed between the reader and the management system.

Best market self-protection

The innovative tamper protection system protects sensitive data and gives the possibility to delete the authentication keys (patented solution). Unlike the current solutions on the market, the reliability of the accelerometer based technology avoids it being outsmarted.

Picture showing the self-protection of the ARCS-J/BT by STid Industry

Standing the test of time

Designed to push the boundaries, the Architect® Blue Hybrid keypad reader design has been developed to withstand harsh environments, to operate outside (IP65 level) and to offer a high impact resistance (IK08).

Download the resistance reportVideo of the ARCS-J/BT's crash test

Picture showing the resistance of the ARCS-J/BT by STid Industry

Create your own scalable configuration

The Architect® Blue series is intuitive and dynamic, made up of 6 interchangeable modules, easy to connect to a smart common RFID core & Bluetooth®.

The easy and cost saving modularity concept allows you to keep control of the access security management.

STid Schema ARC evolutivite BT US

Let your imagination flow

A signature reflects personal style choices. The design of Architect® Blue readers is immediately recognizable, with a dynamic and elegant style, featuring clean, pure lines.
STid offers a range of customization options to tailor your reader to your corporate identity and integrate it fully into its installation environment.

Datasheet

  • Frequency
    Frequency: 125 kHz +13.56 MHz + Bluetooth®
  • Standards
    Standards: ISO14443A types A & B, ISO18092
  • Chip
    Chip: EM42xx / EM4x50 / Format Wiegand 26, 34, 35 and 37 bits / Nedap / Crosspoint MIFARE Ultralight® & Ultralight® C, MIFARE® Classic & Classic EV1, MIFARE Plus® & Plus® EV1, MIFARE® DESFire® 256, EV1 & EV2, NFC (HCE), SMART MX, CPS3, PicoPass® (CSN only), iCLASS™ (CSN only)* STid Mobile ID® (virtual card), Orange Pack ID
  • Functions
    Functions: Read only: CSN, private ID (sector/file) or Secure Protocol (Secure Plus) / Secure Read Write
  • Interfaces
    Interfaces: TTL protocol Data Clock (ISO2) or Wiegand (ciphered mode Sx1) / RS485 (ciphered mode Sx3) with secure communication protocols SSCP & SSCP2 ; OSDP™ V1 (plain communication) & V2 (SCP secure communication) Compatible with EasySecure interface
  • Reading distances
    Reading distances: Up to 6 cm / 2.36’’ with a 125 kHz card / Up to 6 cm / 2.36’’ with a MIFARE DESFire® EV2 card Up to 20 m / 65.6 ft with a Bluetooth® smartphone (adjustable distances on each reader)
  • Power supply
    Power supply: 7 VDC to 28 VDC / Power requirement 190 mA / 12 VDC
  • Material
    Material: ABS-PC UL-V0 (black) / ASA-PC-UL-V0 UV (white)
  • Color
    Color: black or white - Many shell customization possibilities for 13.56 MHz reader
  • Dimensions (h x w x d)
    Dimensions (h x w x d): 145.64 x 79.93 x 25.7 mm / 5.71’’ x 3.11’’ x 0.98’’ (general tolerance following ISO NFT 58-000 standard)
  • Operating temperatures
    Operating temperatures: - 20°C to + 70°C / - 4°F to + 158°F / Humidity: 0 - 95%
  • Protection
    Protection: IK08 reinforced vandal-proof structure / Accelerometer-based tamper detection system with key deletion option (patented)
  • Resistance
    Resistance: IP65 Level - Weather-resistant with waterproof electronics (CEI NF EN 61086 homologation)

*Our readers can only read the UID/Chip Serial Number. They cannot read secure HID Global’s iCLASS™ cryptographic protections.



Picture of the ARCS-J/BT with its dimensions

picto CE FCC UL

Part numbers

Picto R Read only

Easyline pre-configured offer - Wiegand: ARCS-Rx1-J/PC2-xx/1
Secure - TTL: ARCS-Rx1-I/BT2-xx/y
Secure / Secure Plus - TTL: ARCS-Sx1-I/BT2-xx/y
Secure - RS485: ARCS-Rx3-I/BT2-7AB/y
Secure / Secure Plus - RS485: ARCS-Sx3-I/BT2-7AB/y
Secure / EasySecure interface - RS485: ARCS-Rx3-I/BT2-7AA/y
Secure / Secure Plus / EasySecure interface - RS485: ARCS-Sx3-I/BT2-7AA/y



picto RW Read / write

Secure - SSCP RS485: ARCS-Wx3-I/BT2-7AA/y
Secure - SSCP2 RS485: ARCS-Wx3-I/BT2-7AD/y
Secure - OSDPTM RS485: ARCS-Wx3-I/BT2-7OS/y

y: color casing (1: black - 2: white)
