ARCS-J/BT Easyline - 125 kHz + 13.56 MHz + Bluetooth® pre-configured multi-technology keypad reader

ARCS-J/BT Easyline - 125 kHz + 13.56 MHz + Bluetooth® pre-configured multi-technology keypad reader

STid has designed the Architect® Blue Hybrid vandal-resistant reader combining 125 kHz + 13.56 MHz + Bluetooth® technologies with a capacitive keypad. Synthesis of three identification technologies it facilitates your migrations to advanced levels of security. No configuration is required to use this Easyline reader.

The most awarded access control reader around the world bandeau logo Trophees STid 2017 V2

Logo Architect STid

The perfect blend of high security and scalability

  • Lecteur ARC J gauche
  • Lecteur ARC J face
  • Lecteur ARC J droite

Simplified operation

Flexible interoperable

Interoperable


The reader’s Wiegand output easily interfaces with most existing Wiegand protocol access control panels. Different formats are available: Wiegand 32 or 37 bits.

NOconfiguration

No configuration required


The Architect® Blue Hybrid reader is pre-configured. Plug & Play, no configuration is required to read Easyline RFID or mobile credentials.

Seamless technological migration

The Architect® Blue Hybrid keypad reader makes it easy to manage extensions, upgrades and technology migrations. During a migration or a complex multi-site configuration, it can read a heterogeneous mix of cards.

Schema ARCS J BT easylineUS





visuel migration 480px2

Multi-factor identification

With both reader and keypad available together, the Architect® Blue Easyline reader allows double-factor identification by combining identification by RFID or virtual card and a PIN code.

The Easyline keypad mode operates in "Card or Key" mode in 4-bit format only.

Lecteur Arc J en situation

Welcome to high security

Anssi flat blanc

Easyline offers enhanced security through data encryption and mutual authentication between the card and reader. It uses the latest MIFARE® DESFire® EV2 contactless chip technologies with new data security mechanisms:

  • Secure Messaging EV2: secure transaction method based on AES-128 with protection against interleaving and replay attacks.
  • Proximity Check: improved protection against relay attacks.

By using security-standard encryption and advanced key management mechanisms, Easyline reduces the risk of duplicated card or compromised data.

Standing the test of time

Design to push the boundaries, the Architect® Blue Hybrid keypad reader design has been developed to withstand harsh environments (IP65 level) and to offer a high impact resistance (IK08).

Download resistance reportMiniature vidéo Crashtest Lecteur ARC J - BLuetooth

Lecteur ARC J Bluetooth - Resistance

Datasheet

  • Frequency
    Frequency: 125 kHz + 13.56 MHz + Bluetooth®
  • Standards
    Standards: ISO14443 types A & B, ISO18092 / Certifications: CE (Europe), UKCA (United Kingdom), FCC (USA), IC (Canada), BIS (India), RCM (Australia & New Zealand), UL & RoHS
  • Chip
    Chip: EM42xx / EM4x50 / Wiegand format 26, 34, 35 and 37 bits / Nedap® / Crosspoint® / MIFARE® DESFire® EV2 / STid Mobile ID® (virtual card)
  • Functions
    Functions: Pre-configured secure read only
  • Interfaces
    Interfaces: Wiegand 32 or 37 bits
  • Reading distances
    Reading distances: Up to 8 cm with a 125 kHz card / Up to 8 cm with a MIFARE DESFire® EV2 card / Up to 20 m with a Bluetooth® enabled smartphone (distances adjustable on each reader)
  • Power supply
    Power supply: 7 VDC to 28 VDC / Consumption 210 mA / 12 VDC max
  • Material
    Material: ABS-PC UL-V0 (black)
  • Color
    Color: Black
  • Dimensions (h x w x d)
    Dimensions (h x w x d): 145.64 x 79.93 x 25.7 mm
  • Operating temperatures
    Operating temperatures: - 20°C to + 70°C
  • Protection
    Protection: IK08 certified reinforced vandal-proof structure
  • Resistance
    Resistance: IP65 level (excluding connectors) - Weather, water and dust resistant (CEI NF EN 61086 certification) / Humidity: 0 - 95%

Schéma technique Lecteur ARC J Bluetooth

Logos CE, FCC et UL

Part numbers

Wiegand 32 bits: ARCS-RX1-J/PC2-3LA/1
Wiegand 37 bits: ARCS-RX1-J/PC2-3V/1
