ATX Hybrid Multi-Prox
The ATEX & IECEx certified reader combines compatibility with 125 kHz and 13.56 MHz DESFire® EV3 technologies, offering robust, secure, and versatile access control for hazardous environments. Specifically designed to meet strict safety standards, it ensures intrinsic safety in potentially explosive atmospheres, such as those with flammable gases, vapors, or dust. This reader is an excellent choice for industrial sites requiring durable and compliant solutions for access control and identification.
Standing the Test of Time
The Ex II 2 GD IP66 explosion-proof enclosure of the ATX hydrid multi-prox reader makes it extremely robust in harsh environments (IP66 certified) as well as highly resistant to vandalism (IK10 certified).
ATEX & IECEx Certified Reader
The ATX hybrid multi-prox reader is ATEX (EN60079) & IECEx certified and complies with both European Directives (99/92/CE and 94/9/CE). It is used to control people’s access to highsecurity areas in:
• the chemical and petrochemical industries,
• oil and gas refineries,
• nuclear power plants,
• mines.
Multi-Technology Reader
The ATX hybrid multi-prox reader simplifies management of upgrades, technological migrations and complex multi-site configurations.
125 kHz Prox Technologies
The reader is compatible with many legacy Prox technologies*: EM®, HID Proximity®, AWID®, INDALA®, IOPROX®…
MIFARE® DESFire® EV3
The reader supports for the latest MIFARE® DESFire® EV3 contactless technologies with new data security mechanisms: “Secure Messaging” to secure the transaction and “Proximity Check” to protect against relay attacks.
Open Technologies for Easy Integration
The reader is compatible with many access control systems and accepts the main protocols: Wiegand and OSDP™ v1 & v2.
-
protocols
Wiegand
OSDP™
-
technologies
13.56 MHz MIFARE® DESFire® EV3
125 kHz
-
Frequency13.56 MHz + 125 kHz
-
StandardISO14443 types A & B, ISO18092
-
13.56 MHz CredentialsMIFARE Ultralight® & Ultralight® C, MIFARE® Classic & Classic EV1, MIFARE Plus®, MIFARE® DESFire® 256, EV1, EV2 & EV3, SMART MX, PicoPass®, iCLASS™ (CSN ISO14443A only)
-
125 kHz CredentialsHID Proximity®, INDALA®, IOPROX®, AWID®, EM®
-
KeypadReader_KeypadUndefined
-
Reader_AntennaReader_Antenna_Standard
-
Wiegand InterfaceWiegand 26, 32, 34, 35, 36, 37, 38, 40, 44, 64, 72 bits or custom
-
Inputs/OutputsSolid State Relay | Output Voltage: 60V - Output Current: 0.2A - Typical Resistance: 1Ω for AC/DC | Automatic tamper detection management or OSDP™ command according to the interface
-
ConfigurationsConfiguration by RFID card, software, or controlled by external command (0V) depending on the interface
-
Operating Voltage7 - 28 VDC
-
Operating Temperature-20°C / +70°Cn-4°F / +158°F
-
RobustnessIK10 Certified
-
Mounting4 mounting brackets on the enclosure | Compatible with universal VESA 200 x 200 mounting kits (requires a mounting accessory)
-
CertificationsCE (Europe), UKCA (United Kingdom), FCC (USA), IC (Canada), RCM (Australia & New Zealand), ANRT (Morocco), UL, RoHS, ATEX (EN60079) & IECEx
-
Connections10-pin plug-in connector (5 mm / 0.2 in) 2-pin plug-in connector (5 mm / 0.2 in): O/C contact - Tamper detection signal 2 PE PAP-R0 M20 cable glands for external shielded cables. 10-19 mm (0.39-0.75 in)
-
Current Draw170 mA/12 VDC max
-
ResistanceExplosion-proof enclosure Ex II 2 GD IP66 - Resistant to explosions, weather, water, and dust / IEC60068-2-6 / MIL-STD-810
-
Dimensions & Weight310 x 270 x 174 mm / 12.2 x 10.63 x 6.85 in (general tolerance following ISO NFT 58-000 standard) Weight: 13.5 kg / 476.2 oz
-
Housing Materials & ColorCopper-free marine-grade aluminum, RAL 9006 gray epoxy
-
Range0 - 4 cm / 0 - 1.6 in with a MIFARE® DESFire® EV3 card 0 - 5 cm / 0 - 2 in with a 125 kHz card
-
OSDP Protocols
-
Secure Private ID and/or CSN serial numberATX-WX3-IM/BF5-7OS/3
-
-
Secure Private ID and/or CSN serial number - WiegandATX-RX1-IM/BF5-3x/3
