Nordic ID HH53 is an ideal contemporary data collection tool. The mobile computer is equipped with a large 4.3” touchscreen with an increased processing capability. The new processing capability enables developing more sophisticated and smoothly running applications offering users an ease-of-use experience. This professional PDA is well suited for all your mobile data collection and on-the-fly identification applications to identify vehicles and/or their drivers (car park access control, fleet management…).

  • visuels sliders Medea 001
  • visuels sliders Medea 01


picto performane

High performance

The Nordic ID HH53 terminal is designed for long range read write applications (up to 7 m / 22.97 ft) with high speed, easy and selective contactless identification). It can easily read up to 200 tags/second.
It offers many antenna configurations directly controlled by software: linear, circular or proximity.



A clever blend of design
and ergonomics

Thanks to its optimized grip and use, and a large, high-resolution 4.3"color touch screen, the C-One offers excellent ease-of-use, even in bright sunlight..



on mobility

A 3500 mAh battery enables stand-alone usage of up to, or greater than, 10 hours working-time thanks to our dedicated power-management (16 hours of intensive use with the optional 7000 mAh battery).


  • Large and robust daylight readable
    4.3” touchscreen
  • High processing capability
  • Operates a full working day with
    only one charge
  • Several connectivity option


Picto Sur mesure

Reading accuracy and reliability

The UHF terminal is designed for fast, accurate and reliable data collection, whether it is a short-range RFID reading or an intensive RFID inventory.


Multi technos

Upgradable multi-technology terminal

The Nordic ID HH53 Terminal can be combined with an optional module to identify barcodes. It has an adaptive laser to the ranges: standard, long and auto-range.


ik10 picto71px

Robustness and reliability

It stands out from consumer products through its unflinchingly rugged construction. Built to International Standard IP54, it will withstand multiple falls of 1.50 m / 4.92 ft on to concrete and remain fully operational within a temperature range of -20°C to +55°C / -4°F to +131°F.

Data sheet

  • Frequency
    Frequency: UHF
  • Standards
    Standards: ISO18000-63 / EPC1 Gen 2 - ETSI 865.6 - 867.6 MHz or FCC/IC 902 - 928 MHz / RF power: ERP +33 dBm (2 W) / CE & FCC certifications
  • Chip
    Chip: EPC1 Gen 2
  • Functions
    Functions: Read write
  • Interfaces
    Interfaces: 2D Imager / Dual band WLAN (a/b/g/n) / Bluetooth®
  • Reading distances
    Reading distances: 0 - 7 m / 0 - 22.97 ft - Up to 200 tags/second
  • Power supply
    Power supply: Rechargeable, removable Lithium-Ion battery 3500/7000 mAh, 3.7V Up to 10/16 h in intensive use. Dock station included
  • Color
    Color: Black
  • Dimensions (h x w x d)
    Dimensions (h x w x d): 196 x 83/91 x 21/135 mm / 7.72’’ x 3.27’’/3.58’’ x 0.83’’/5.32’’ - Weight: 550 g including the battery
  • Operating temperatures
    Operating temperatures: -20°C to +55°C / -4°F to + 131°F
  • Protection
    Protection: Multiples drops on 1.5 m / 4.92 ft - ESD contacts: +/- 4kVdc / Air discharge: +/- 8kVdc
  • Resistance
    Resistance: IP54 - Water projection and dust resistant / Humidity: 10 - 95%
  • Processor and memory
    Processor and memory: ARM Cortex-A8 1 GHz / Memory: 512 MB LPDDR2 - RAM 4 GB Flash
  • Operating system
    Operating system: Android
  • Touchscreen
    Touchscreen: 4,3" WVGA capacitive touch screen, 800 x 480 pixels, 262k colors Adjustable LED backlight, Daylight readable (Blanview), Gorilla glass 2


Part numbers


HH53 Android UHF handled Terminal + 1D/2D codes + Dock station - 865-868 MHz:


HH53 - Android UHF handled Terminal + 1D/2D codes + Dock station - 902-928 MHz:
